GV13DC-12 digital display generator instrument

Module overview

GV13DC-12 is a lightweight, low-cost module used to measure and display generator voltage, frequency, and running time. It can replace traditional pointer meters and achieve multiple uses in one meter. The module is fixed with conventional bolts, which is safe, convenient and strong.

Features

Able to measure voltage, frequency, accumulated running time, and current running time at the same time

4-digit high-brightness LED digital tube displays measured values

With screen changing button

DC voltage supply

Parameter display

Phase voltage V

Frequency Hz

Accumulated running time H

Current running time T

Range and accuracy

Voltage: AC30～450V, error ≦±1%

Frequency: 20-70HZ, error ≦±0.5%

Accumulated running time: 0-9999H

Current running time: 0-999.9H

Specifications

Working power supply: DC8-36V

Power consumption: MAX: 1 W

Operating temperature range: -30℃ ~ 70℃

Volume size (W * H * D): 58mm * 54mm * 41mm

Installation opening (W * H): 47mm * 37mm

Weight: 55g
